HD1760JL ST TRANS NPN 800V 36A TO-264
HD1760JL Images
HD1760JL Images
HD1760JL
  • Manufacturer: STMicroelectronics(ST)
  • Category: Discrete Semiconductor Products~Transistors - Bipolar (BJT) - Single Package/Case: TO-264-3, TO-264AA
  • Description: TRANS NPN 800V 36A TO-264
  • COMPETITIVE PRICE and DELIVERY TIME
  • Order with confidence, there are no lead times for in-stock products.
Quickly Quote for You to Meet Your Target Price, Support Small Order Quantity with Fast Quick Delivery.
Download Datasheet (PDF)
HD1760JL Datasheet
ELECTRONIC COMPONENTS, CHOOSE NHE ELECTRONICS
HD1760JL Specifications:
  • MfrPart.: HD1760JL
  • Mfr: STMicroelectronics
  • Description: TRANS NPN 800V 36A TO-264
  • Product Category: Discrete Semiconductor Products~Transistors - Bipolar (BJT) - Single
  • Package: Tube
  • Series: -
  • PartStatus: Obsolete
  • TransistorType: NPN
  • Current-Collector(Ic)(Max): 36 A
  • Voltage-CollectorEmitterBreakdown(Max): 800 V
  • VceSaturation(Max)@IbIc: 2V @ 4.5A, 18A
  • Current-CollectorCutoff(Max): 200µA
  • DCCurrentGain(hFE)(Min)@IcVce: 5 @ 18A, 5V
  • Power-Max: 200 W
  • Frequency-Transition: -
  • OperatingTemperature: 150°C (TJ)
  • MountingType: Through Hole
  • Package/Case: TO-264-3, TO-264AA
  • HD1760JL STMicroelectronics, TRANS NPN 800V 36A TO-264, Discrete Semiconductor Products~Transistors - Bipolar (BJT) - Single
