BD681 Images
- Manufacturer: STMicroelectronics(ST)
- Category: Discrete Semiconductor Products~Transistors - Bipolar (BJT) - Single Package/Case: TO-225AA, TO-126-3
- Description: TRANS NPN DARL 100V 4A SOT-32
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
BD681 Specifications:
- MfrPart.: BD681
- Mfr: STMicroelectronics
- Description: TRANS NPN DARL 100V 4A SOT-32
- Product Category: Discrete Semiconductor Products~Transistors - Bipolar (BJT) - Single
- Package: Tube
- Series: -
- PartStatus: Active
- TransistorType: NPN - Darlington
- Current-Collector(Ic)(Max): 4 A
- Voltage-CollectorEmitterBreakdown(Max): 100 V
- VceSaturation(Max)@IbIc: 2.5V @ 30mA, 1.5A
- Current-CollectorCutoff(Max): 500µA
- DCCurrentGain(hFE)(Min)@IcVce: 750 @ 1.5A, 3V
- Power-Max: 40 W
- Frequency-Transition: -
- OperatingTemperature: 150°C (TJ)
- MountingType: Through Hole
- Package/Case: TO-225AA, TO-126-3
- BD681 STMicroelectronics, TRANS NPN DARL 100V 4A SOT-32, Discrete Semiconductor Products~Transistors - Bipolar (BJT) - Single
BD681, ST authentic parts in stock from STMicroelectronics authorized distributors, order today, can ship immediately.
