BAT54FILM Images
- Manufacturer: STMicroelectronics(ST)
- Category: Discrete Semiconductor Products~Diodes - Rectifiers - Single Package / Case: TO-236-3, SC-59, SOT-23-3
- Description: DIODE SCHOTTKY 40V 300MA SOT23-3
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
BAT54FILM Specifications:
- Manufacturer Product Number: BAT54FILM
- Mfr: STMicroelectronics
- Detailed Description: DIODE SCHOTTKY 40V 300MA SOT23-3
- Product Category: Discrete Semiconductor Products~Diodes - Rectifiers - Single
- Package: Tape & Reel (TR),Cut Tape (CT)
- Series: -
- Part Status: Active
- Diode Type: Schottky
- Voltage - DC Reverse (Vr) (Max): 40 V
- Current - Average Rectified (Io): 300mA (DC)
- Voltage - Forward (Vf) (Max) @ If: 900 mV @ 100 mA
- Speed: Fast Recovery =< 500ns, > 200mA (Io)
- Reverse Recovery Time (trr): 5 ns
- Current - Reverse Leakage @ Vr: 1 µA @ 30 V
- Capacitance @ Vr, F: 10pF @ 1V, 1MHz
- Mounting Type: Surface Mount
- Package / Case: TO-236-3, SC-59, SOT-23-3
- Operating Temperature - Junction: -40°C ~ 150°C
- BAT54FILM STMicroelectronics, DIODE SCHOTTKY 40V 300MA SOT23-3, Discrete Semiconductor Products~Diodes - Rectifiers - Single
BAT54FILM, ST authentic parts in stock from STMicroelectronics authorized distributors, order today, can ship immediately.
