BAT54CFILM Images
- Manufacturer: STMicroelectronics(ST)
- Category: Discrete Semiconductor Products~Diodes - Rectifiers - Arrays Package / Case: TO-236-3, SC-59, SOT-23-3
- Description: DIODE ARRAY SCHOTTKY 40V SOT23-3
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
BAT54CFILM Specifications:
- Mfr Part: BAT54CFILM
- Mfr: STMicroelectronics
- Description: DIODE ARRAY SCHOTTKY 40V SOT23-3
- Product Category: Discrete Semiconductor Products~Diodes - Rectifiers - Arrays
- Item12: Tape & Reel (TR),Cut Tape (CT)
- Series: -
- Part Status: Active
- Diode Configuration: 1 Pair Common Cathode
- Diode Type: Schottky
- Voltage - DC Reverse (Vr) (Max): 40 V
- Current - Average Rectified (Io) (per Diode): 300mA (DC)
- Voltage - Forward (Vf) (Max) @ If: 900 mV @ 100 mA
- Speed: Fast Recovery =< 500ns, > 200mA (Io)
- Current - Reverse Leakage @ Vr: 1 µA @ 30 V
- Operating Temperature - Junction: -40°C ~ 150°C
- Mounting Type: Surface Mount
- Package / Case: TO-236-3, SC-59, SOT-23-3
- BAT54CFILM STMicroelectronics, DIODE ARRAY SCHOTTKY 40V SOT23-3, Discrete Semiconductor Products~Diodes - Rectifiers - Arrays
BAT54CFILM, ST authentic parts in stock from STMicroelectronics authorized distributors, order today, can ship immediately.
