A2P75S12M3-F Images
- Manufacturer: STMicroelectronics(ST)
- Category: Discrete Semiconductor Products~Transistors - IGBTs - Modules Package/Case: Module
- Description: IGBT MOD 1200V 75A ACEPACK2
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
A2P75S12M3-F Specifications:
- MfrPart.: A2P75S12M3-F
- Mfr: STMicroelectronics
- Description: IGBT MOD 1200V 75A ACEPACK2
- Product Category: Discrete Semiconductor Products~Transistors - IGBTs - Modules
- Package: Tray
- Series: -
- PartStatus: Active
- IGBTType: Trench Field Stop
- Configuration: Three Phase Inverter
- Voltage-CollectorEmitterBreakdown(Max): 1200 V
- Current-Collector(Ic)(Max): 75 A
- Power-Max: 454.5 W
- Vce(on)(Max)@VgeIc: 2.3V @ 15V, 75A
- Current-CollectorCutoff(Max): 100 µA
- InputCapacitance(Cies)@Vce: 4700 pF @ 25 V
- Input: Standard
- NTCThermistor: Yes
- OperatingTemperature: -40°C ~ 150°C (TJ)
- MountingType: Chassis Mount
- Package/Case: Module
- A2P75S12M3-F STMicroelectronics, IGBT MOD 1200V 75A ACEPACK2, Discrete Semiconductor Products~Transistors - IGBTs - Modules
