74AC02B Images
- Manufacturer: STMicroelectronics(ST)
- Category: Integrated Circuits (ICs)~Logic - Gates and Inverters SupplierDevicePackage: 14-DIP
- Description: IC GATE NOR 4CH 2-INP 14DIP
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
74AC02B Specifications:
- MfrPart.: 74AC02B
- Mfr: STMicroelectronics
- Description: IC GATE NOR 4CH 2-INP 14DIP
- Product Category: Integrated Circuits (ICs)~Logic - Gates and Inverters
- Package: Tube
- Series: 74AC
- PartStatus: Obsolete
- LogicType: NOR Gate
- NumberofCircuits: 4
- NumberofInputs: 2
- Features: -
- Voltage-Supply: 2V ~ 6V
- Current-Quiescent(Max): 2 µA
- Current-OutputHighLow: 24mA, 24mA
- LogicLevel-Low: 0.9V ~ 1.65V
- LogicLevel-High: 2.1V ~ 3.85V
- MaxPropagationDelay@VMaxCL: 8ns @ 5V, 50pF
- OperatingTemperature: -55°C ~ 125°C
- MountingType: Through Hole
- SupplierDevicePackage: 14-DIP
- 74AC02B STMicroelectronics, IC GATE NOR 4CH 2-INP 14DIP, Integrated Circuits (ICs)~Logic - Gates and Inverters
