2N4923 Images
- Manufacturer: STMicroelectronics(ST)
- Category: Discrete Semiconductor Products~Transistors - Bipolar (BJT) - Single Package/Case: TO-225AA, TO-126-3
- Description: TRANS NPN 80V 1A SOT-32
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
2N4923 Specifications:
- MfrPart.: 2N4923
- Mfr: STMicroelectronics
- Description: TRANS NPN 80V 1A SOT-32
- Product Category: Discrete Semiconductor Products~Transistors - Bipolar (BJT) - Single
- Package: Tube
- Series: -
- PartStatus: Obsolete
- TransistorType: NPN
- Current-Collector(Ic)(Max): 1 A
- Voltage-CollectorEmitterBreakdown(Max): 80 V
- VceSaturation(Max)@IbIc: 600mV @ 100mA, 1A
- Current-CollectorCutoff(Max): 500µA
- DCCurrentGain(hFE)(Min)@IcVce: 30 @ 500mA, 1V
- Power-Max: 30 W
- Frequency-Transition: 3MHz
- OperatingTemperature: 150°C (TJ)
- MountingType: Through Hole
- Package/Case: TO-225AA, TO-126-3
- 2N4923 STMicroelectronics, TRANS NPN 80V 1A SOT-32, Discrete Semiconductor Products~Transistors - Bipolar (BJT) - Single
2N4923, ST authentic parts in stock from STMicroelectronics authorized distributors, order today, can ship immediately.
