2N3773 Images
- Manufacturer: STMicroelectronics(ST)
- Category: Discrete Semiconductor Products~Transistors - Bipolar (BJT) - Single Package/Case: TO-204AA, TO-3
- Description: TRANS NPN 140V 16A TO-3
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
2N3773 Specifications:
- MfrPart.: 2N3773
- Mfr: STMicroelectronics
- Description: TRANS NPN 140V 16A TO-3
- Product Category: Discrete Semiconductor Products~Transistors - Bipolar (BJT) - Single
- Package: Bulk
- Series: -
- PartStatus: Obsolete
- TransistorType: NPN
- Current-Collector(Ic)(Max): 16 A
- Voltage-CollectorEmitterBreakdown(Max): 140 V
- VceSaturation(Max)@IbIc: 4V @ 3.2A, 16A
- Current-CollectorCutoff(Max): 10mA
- DCCurrentGain(hFE)(Min)@IcVce: 15 @ 8A, 4V
- Power-Max: 150 W
- Frequency-Transition: -
- OperatingTemperature: 200°C (TJ)
- MountingType: Chassis Mount
- Package/Case: TO-204AA, TO-3
- 2N3773 STMicroelectronics, TRANS NPN 140V 16A TO-3, Discrete Semiconductor Products~Transistors - Bipolar (BJT) - Single
2N3773, ST authentic parts in stock from STMicroelectronics authorized distributors, order today, can ship immediately.
