2N3055 Images
- Manufacturer: STMicroelectronics(ST)
- Category: Discrete Semiconductor Products~Transistors - Bipolar (BJT) - Single Package/Case: TO-204AA, TO-3
- Description: TRANS NPN 60V 15A TO-3
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
2N3055 Specifications:
- MfrPart.: 2N3055
- Mfr: STMicroelectronics
- Description: TRANS NPN 60V 15A TO-3
- Product Category: Discrete Semiconductor Products~Transistors - Bipolar (BJT) - Single
- Package: Tray
- Series: -
- PartStatus: Obsolete
- TransistorType: NPN
- Current-Collector(Ic)(Max): 15 A
- Voltage-CollectorEmitterBreakdown(Max): 60 V
- VceSaturation(Max)@IbIc: 3V @ 3.3A, 10A
- Current-CollectorCutoff(Max): 700µA
- DCCurrentGain(hFE)(Min)@IcVce: 20 @ 4A, 4V
- Power-Max: 115 W
- Frequency-Transition: -
- OperatingTemperature: 200°C (TJ)
- MountingType: Chassis Mount
- Package/Case: TO-204AA, TO-3
- 2N3055 STMicroelectronics, TRANS NPN 60V 15A TO-3, Discrete Semiconductor Products~Transistors - Bipolar (BJT) - Single
