1N5821 ST DIODE SCHOTTKY 30V 3A DO201AD
1N5821 Images
1N5821 Images
  • Manufacturer: STMicroelectronics(ST)
  • Category: Discrete Semiconductor Products~Diodes - Rectifiers - Single Package / Case: DO-201AD, Axial
  • Description: DIODE SCHOTTKY 30V 3A DO201AD
  • COMPETITIVE PRICE and DELIVERY TIME
  • Order with confidence, there are no lead times for in-stock products.
Quickly Quote for You to Meet Your Target Price, Support Small Order Quantity with Fast Quick Delivery.
Download Datasheet (PDF)
1N5821 Datasheet
ELECTRONIC COMPONENTS, CHOOSE NHE ELECTRONICS
1N5821 Specifications:
  • Manufacturer Product Number: 1N5821
  • Mfr: STMicroelectronics
  • Detailed Description: DIODE SCHOTTKY 30V 3A DO201AD
  • Product Category: Discrete Semiconductor Products~Diodes - Rectifiers - Single
  • Package: Tape & Box (TB)
  • Series: -
  • Part Status: Obsolete
  • Diode Type: Schottky
  • Voltage - DC Reverse (Vr) (Max): 30 V
  • Current - Average Rectified (Io): 3A
  • Voltage - Forward (Vf) (Max) @ If: 500 mV @ 3 A
  • Speed: Fast Recovery =< 500ns, > 200mA (Io)
  • Reverse Recovery Time (trr): -
  • Current - Reverse Leakage @ Vr: 2 mA @ 30 V
  • Capacitance @ Vr, F: -
  • Mounting Type: Through Hole
  • Package / Case: DO-201AD, Axial
  • Operating Temperature - Junction: 150°C (Max)
  • 1N5821 STMicroelectronics, DIODE SCHOTTKY 30V 3A DO201AD, Discrete Semiconductor Products~Diodes - Rectifiers - Single
1N5821, ST authentic parts in stock from STMicroelectronics authorized distributors, order today, can ship immediately.
